CITROËN C4 Picasso (2016 - 2018)

Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Table of contents:

Variants

Minivan
C4 Picasso
BodyMinivan
Length4428 mm
Height1610 mm
Doors5
Boot space537 l
Minivan
Grand C4 Picasso
BodyMinivan
Length4597 mm
Height1638 mm
Doors5
Boot space645 l

Model specs

Model info

Model name
CITROËN C4 Picasso
Generation
3
Production years
2016 - 2018
Generation name
3
  • citroen LogoCitroen C4 Picasso (This) 3
    3.0
Doors
5
5

Dimensions

Length
4428 mm
4,403.0
Avg
4,963.0
Higher is better
Wheelbase
2785 mm
2,725.0
Avg
3,000.0
Higher is better
Width
1826 mm
1,784.0
Avg
2,050.0
Higher is better
Height
1610 mm
1,435.0
Avg
2,254.0
Higher is better
Turning circle
10 m
10.0
Avg
11.0
Lower is better

Boot/interior

Boot space
537 l
160.0
Avg
1,121.0
Higher is better
Seats
5
5
Doors
5
5

Engines/drivetrain

Cylinders
3 - 4
3.0
Avg
4.0
Higher is better
Max. speed
176 - 210 km/h
145.0
Avg
197.0
Higher is better
Torque
205 - 370 Nm
175.0
Avg
310.0
Higher is better
Power
73 - 121 kW
73.0
Avg
150.0
Higher is better
Cubic capacity
1199 - 1997 ccm
999.0
Avg
1,998.0
Higher is better
Acceleration 0-100km/h
9 - 14 s
9.0
Avg
12.0
Higher is better

Consumption/ecology

Tank size
55 - 57 l
50.0
Avg
81.0
Higher is better
Combined consumption (NEDC)
3 - 5 l/100km
3.0
Avg
6.0
Higher is better
City consumption (NEDC)
4 - 7 l/100km
4.0
Avg
8.0
Higher is better
Empty weight (EU)
1355 - 1549 kg
1,280.0
Avg
2,487.0
Higher is better

Towing

Max. towbar load
70 kg
70.0
Avg
100.0
Higher is better
Max. roof load
70 kg
70.0
Avg
150.0
Higher is better
Braked trailer
1330 - 1750 kg
400.0
Avg
2,500.0
Higher is better
Trailer (no brakes)
640 - 750 kg
400.0
Avg
750.0
Higher is better

Engines (C4 Picasso)

Filter by fuel:
Diesel
MAN FWD
BlueHDi 100 Stop&Start Live
Engine & Power
Power
73 kW / 99 HP
Capacity
1.6L (1,560 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
14 s
Max. speed
176 km/h
Torque & RPM
Torque
254 Nm
Consumption
Combined consumption (NEDC)
3 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
4 l/100km
Technical Details
Maximum output at RPM
3750 RPM
Fuel injection
Common Rail
Gasoline
MAN FWD
PureTech 110 Stop&Start Start
Engine & Power
Power
81 kW / 110 HP
Capacity
1.2L (1,199 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
12 s
Max. speed
187 km/h
Torque & RPM
Torque
205 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1500 RPM
City consumption (NEDC)
6 l/100km
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Diesel
MAN FWD
BlueHDi 120 Stop&Start Feel
Engine & Power
Power
88 kW / 120 HP
Capacity
1.6L (1,560 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
12 s
Max. speed
189 km/h
Torque & RPM
Torque
300 Nm
Consumption
Combined consumption (NEDC)
3 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
4 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
BlueHDi 120 Stop&Start Feel EAT6
Engine & Power
Power
88 kW / 120 HP
Capacity
1.6L (1,560 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
12 s
Max. speed
188 km/h
Torque & RPM
Torque
300 Nm
Consumption
Combined consumption (NEDC)
3 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
4 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Gasoline
MAN FWD
PureTech 130 Stop&Start Feel
Engine & Power
Power
96 kW / 131 HP
Capacity
1.2L (1,199 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
11 s
Max. speed
201 km/h
Torque & RPM
Torque
230 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
6 l/100km
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Gasoline
AUT FWD
Grand C4 Picasso PureTech 130 Stop&Start Selection EAT6
Engine & Power
Power
96 kW / 131 HP
Capacity
1.2L (1,199 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
11 s
Max. speed
206 km/h
Torque & RPM
Torque
230 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
6 l/100km
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Diesel
MAN FWD
BlueHDi 150 Stop&Start Selection
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
210 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (NEDC)
4 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
4 l/100km
Technical Details
Maximum output at RPM
4000 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
BlueHDi 150 Stop&Start Selection EAT6
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
207 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (NEDC)
4 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
4000 RPM
Fuel injection
Common Rail
Gasoline
AUT FWD
THP 165 Stop&Start Selection EAT6
Engine & Power
Power
121 kW / 165 HP
Capacity
1.6L (1,598 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
210 km/h
Torque & RPM
Torque
240 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1400 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
6000 RPM
Fuel injection
Direct Injection
Compare all engines

CITROËN C4 Picasso generations

Body type
C4 Picasso 1.Generation
2007 - 2013
Length4468 mm
Height1665 mm
Wheelbase2728 mm
Length4468 mm
Body type
C4 Picasso 2.Generation
2013 - 2016
Length4428 mm
Height1610 mm
Wheelbase2785 mm
Length4428 mm (-40 mm)
C4 Picasso 2.Generation (1. Facelift)
2016 - 2018
Length4428 mm
Height1610 mm
Wheelbase2785 mm
Length4428 mm
Compare all generations

1919
1919
Citroen founded
2007
2007
1.Generation was introduced.
2013
2013
2.Generation was introduced and replaced 1.Generation.
2016
2016
2.Generation (1. Facelift) was introduced and replaced 2.Generation.
2018
2018
The production of CITROËN C4 Picasso was discontinued.
