Toyota Hilux
Specs, engines, generations

Thumbnail 1
Table of contents:

Model specs

Model info

Model name
Toyota Hilux
Generation
AN1P
Production years
2020 - Present
Doors
2
2

Dimensions

Length
5325 mm
5,080.0
Avg
5,500.0
Higher is better
Wheelbase
3085 mm
3,085.0
Avg
3,300.0
Higher is better
Width
1800 mm
1,800.0
Avg
1,997.0
Higher is better
Height
1795 mm
1,790.0
Avg
1,973.0
Higher is better
Ground clearance
227 mm
187.0
Avg
266.0
Higher is better
Turning circle
12 m
11.0
Avg
13.0
Lower is better

Boot/interior

Seats
2
2
Doors
2
2

Engines/drivetrain

Cylinders
4
4.0
Avg
6.0
Higher is better
Max. speed
170 - 175 km/h
120.0
Avg
190.0
Higher is better
Torque
400 - 500 Nm
300.0
Avg
700.0
Higher is better
Power
110 - 150 kW
81.0
Avg
325.0
Higher is better
Cubic capacity
2393 - 2755 ccm
1,898.0
Avg
2,956.0
Higher is better
Acceleration 0-100km/h
10 - 13 s
5.0
Avg
16.0
Higher is better

Consumption/ecology

Tank size
80 l
75.0
Avg
80.0
Higher is better
Combined consumption (WLTP)
8 - 10 l/100km
7.0
Avg
26.0
Higher is better
Suburban consumption (WLTP)
9 l/100km
6.0
Avg
13.0
Higher is better
Consumption on highways (WLTP)
10 l/100km
7.0
Avg
14.0
Higher is better
CO2 emissions (WLTP)
227 - 264 g/km
183.0
Avg
315.0
Higher is better
Empty weight (EU)
1960 - 2295 kg
1,960.0
Avg
2,925.0
Higher is better

Towing

Max. towbar load
120 - 140 kg
100.0
Avg
245.0
Higher is better
Max. roof load
50 kg
50.0
Avg
200.0
Higher is better
Braked trailer
2800 - 3500 kg
1,000.0
Avg
3,500.0
Higher is better
Trailer (no brakes)
750 kg
750.0
Avg
750.0
Higher is better

Offroad

Ramp angle
23 °
16.0
Avg
24.0
Higher is better
Maximum incline
90 °
  • toyota LogoToyota Hilux (This) 90 °
    90.0
Departure angle
25 - 26 °
22.0
Avg
27.0
Higher is better
Approach angle
29 °
27.0
Avg
32.0
Higher is better
Fording
700 mm
550.0
Avg
850.0
Higher is better

Engines (Hilux)

Diesel
MAN Hinterrad
Single Cab 2.4 D-4D Duty 4x2
Engine & Power
Power
110 kW / 150 HP
Capacity
2.4L (2,393 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
13 s
Max. speed
170 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
9 l/100km
Emissions
CO2 emissions (WLTP)
242 g/km
Maximum torque at RPM
1600 RPM
Technical Details
Maximum output at RPM
3400 RPM
Fuel injection
Common Rail
Diesel
AUT AWD
Double Cab 2.4 D-4D Comfort 4x4 Automatik
Engine & Power
Power
110 kW / 150 HP
Capacity
2.4L (2,393 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
12 s
Max. speed
170 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
9 l/100km
Emissions
CO2 emissions (WLTP)
259 g/km
Maximum torque at RPM
1600 RPM
Consumption on short trips (WLTP)
11 l/100km
Technical Details
Maximum output at RPM
3400 RPM
Fuel injection
Common Rail
Diesel
MAN AWD
Double Cab 2.8 D-4D Duty 4x4
Engine & Power
Power
150 kW / 204 HP
Capacity
2.8L (2,755 ccm)
Cylinders
4
Performance
Max. speed
175 km/h
Torque & RPM
Torque
420 Nm
Consumption
Combined consumption (WLTP)
9 l/100km
Emissions
CO2 emissions (WLTP)
253 g/km
Maximum torque at RPM
3400 RPM
Consumption on short trips (WLTP)
11 l/100km
Technical Details
Maximum output at RPM
3000 RPM
Fuel injection
Common Rail
Diesel
AUT AWD
Double Cab 2.8 D-4D Exexcutive 4x4 Automatik
Engine & Power
Power
150 kW / 204 HP
Capacity
2.8L (2,755 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
175 km/h
Torque & RPM
Torque
500 Nm
Consumption
Combined consumption (WLTP)
9 l/100km
Emissions
CO2 emissions (WLTP)
240 g/km
Maximum torque at RPM
1600 RPM
Technical Details
Maximum output at RPM
3000 RPM
Fuel injection
Common Rail
Compare all engines

Toyota Hilux generations

Body type
Hilux RZN
1997 - 2001
Length4725 mm
Height1615 mm
Wheelbase2850 mm
Length4725 mm
Body type
Hilux RZN (1. Facelift)
2001 - 2005
Length4785 mm
Height1595 mm
Wheelbase2850 mm
Length4785 mm (+60 mm)
Body type
Hilux N25
2005 - 2008
Length5255 mm
Height1680 mm
Wheelbase3085 mm
Length5255 mm (+470 mm)
Hilux N25 (1. Facelift)
2008 - 2011
Length5255 mm
Height1680 mm
Wheelbase3085 mm
Length5255 mm
Body type
Hilux N25 (2. Facelift)
2011 - 2016
Length5260 mm
Height1795 mm
Wheelbase3085 mm
Length5260 mm (+5 mm)
Body type
Hilux AN1P
2016 - 2020
Length5330 mm
Height1810 mm
Wheelbase3085 mm
Length5330 mm (+70 mm)
Hilux Hilux AN1P (1. Facelift)
2020 - Now
Length5325 mm
Height1815 mm
Wheelbase3085 mm
Length5325 mm (-5 mm)
Compare all generations

1937
1937
Toyota founded
1997
1997
RZN was introduced.
2001
2001
RZN (1. Facelift) was introduced and replaced RZN.
2005
2005
N25 was introduced and replaced RZN (1. Facelift).
2008
2008
N25 (1. Facelift) was introduced and replaced N25.
2011
2011
N25 (2. Facelift) was introduced and replaced N25 (1. Facelift).
2016
2016
AN1P was introduced and replaced N25 (2. Facelift).
2020
2020
Hilux AN1P (1. Facelift) was introduced and replaced AN1P.
