VW Commercial Crafter (2006 - 2011)

Table of contents:

Model specs

Model info

Model name
VW Nutzfahrzeuge Crafter
Generation
2EC*/2EK*/2F*
Production years
2006 - 2011
Doors
4
4

Dimensions

Length
5240 mm
4,527.0
Avg
5,531.0
Higher is better
Wheelbase
3250 mm
2,786.0
Avg
3,300.0
Higher is better
Width
1993 mm
1,784.0
Avg
2,059.0
Higher is better
Height
2415 mm
1,668.0
Avg
2,533.0
Higher is better
Turning circle
12 m
11.0
Avg
12.0
Lower is better

Boot/interior

Boot space
7500 l
117.0
Avg
7,500.0
Higher is better
Seats
2
2
Max. seats
9
9
Doors
4
4

Engines/drivetrain

Cylinders
5
3.0
Avg
5.0
Higher is better
Max. speed
133 - 158 km/h
133.0
Avg
189.0
Higher is better
Torque
220 - 350 Nm
175.0
Avg
430.0
Higher is better
Power
65 - 120 kW
65.0
Avg
180.0
Higher is better
Cubic capacity
2459 ccm
999.0
Avg
2,459.0
Higher is better

Consumption/ecology

Tank size
75 l
50.0
Avg
81.0
Higher is better
Combined consumption (NEDC)
9 - 10 l/100km
5.0
Avg
9.0
Higher is better
City consumption (NEDC)
11 - 14 l/100km
6.0
Avg
13.0
Higher is better
Empty weight (EU)
1971 - 2263 kg
1,280.0
Avg
2,385.0
Higher is better

Towing

Max. towbar load
100 kg
75.0
Avg
100.0
Higher is better
Max. roof load
150 - 300 kg
75.0
Avg
300.0
Higher is better
Braked trailer
2000 - 2800 kg
1,000.0
Avg
2,500.0
Higher is better

Engines (Crafter)

Diesel
MAN Hinterrad
VW -Commercial vehicle Crafter 35 2.5 TDI Kombi kurz
Engine & Power
Power
65 kW / 88 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
136 km/h
Torque & RPM
Torque
220 Nm
Consumption
Combined consumption (NEDC)
9 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
13 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN Hinterrad
VW -Commercial vehicle Crafter 30 2.5 TDI Kombi mittel
Engine & Power
Power
80 kW / 109 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
147 km/h
Torque & RPM
Torque
280 Nm
Consumption
Combined consumption (NEDC)
9 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
13 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT Hinterrad
VW -Commercial vehicle Crafter 30 2.5 TDI Kombi kurz Shiftmatic
Engine & Power
Power
80 kW / 109 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
147 km/h
Torque & RPM
Torque
280 Nm
Consumption
Combined consumption (NEDC)
9 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
11 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN Hinterrad
VW -Commercial vehicle Crafter 30 2.5 TDI Kombi kurz
Engine & Power
Power
100 kW / 136 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
154 km/h
Torque & RPM
Torque
300 Nm
Consumption
Combined consumption (NEDC)
10 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
14 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT Hinterrad
VW -Commercial vehicle Crafter 30 2.5 TDI Kombi mittel Shiftmatic
Engine & Power
Power
100 kW / 136 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
154 km/h
Torque & RPM
Torque
300 Nm
Consumption
Combined consumption (NEDC)
9 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
11 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN Hinterrad
VW -Commercial vehicle Crafter 35 2.5 TDI Hochdach-Kombi mittel
Engine & Power
Power
120 kW / 163 HP
Capacity
2.5L (2,459 ccm)
Cylinders
5
Performance
Max. speed
156 km/h
Torque & RPM
Torque
350 Nm
Consumption
Combined consumption (NEDC)
10 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
13 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Compare all engines

VW Commercial Crafter generations

Body type
Crafter I
2006 - 2011
Length5905 mm
Height2415 mm
Wheelbase3665 mm
Length5905 mm
Body type
Crafter Crafter I (1. Facelift)
2011 - 2016
Length5240 mm
Height2415 mm
Wheelbase3250 mm
Length5240 mm (-665 mm)
Crafter Crafter II
2017 - Now
Length7391 mm
Height2798 mm
Wheelbase4490 mm
Length7391 mm (+2 151 mm)
Compare all generations

2006
2006
I was introduced.
2011
2011
Crafter I (1. Facelift) was introduced and replaced I.
2016
2016
Crafter I (1. Facelift) was introduced and replaced I.
2017
2017
Crafter II was introduced.
