Volvo XC40
Specs, engines, generations

Thumbnail 1
Thumbnail 1
Thumbnail 1
Table of contents:

Variants

SUV
XC40
BodySUV
Length4425 mm
Height1652 mm
Doors5
Boot space433 l
SUV
XC40 Recharge Plug-in Hybrid
BodySUV
Length4425 mm
Height1652 mm
Doors5
Boot space405 l
SUV
XC40 Recharge Pure Electric
BodySUV
Length4425 mm
Height1647 mm
Doors5
Boot space419 l

Model specs

Model info

Model name
Volvo XC40
Generation
X
Production years
2022 - Present
Doors
5
5

Dimensions

Length
4425 mm
  • volvo LogoVolvo XC40 (This) 4425 mm
    4,425.0
Wheelbase
2702 mm
  • volvo LogoVolvo XC40 (This) 2702 mm
    2,702.0
Width
1863 mm
  • volvo LogoVolvo XC40 (This) 1863 mm
    1,863.0
Height
1652 mm
  • volvo LogoVolvo XC40 (This) 1652 mm
    1,652.0
Ground clearance
205 mm
  • volvo LogoVolvo XC40 (This) 205 mm
    205.0
Turning circle
11 m
  • volvo LogoVolvo XC40 (This) 11 m
    11.0

Boot/interior

Boot space
433 l
  • volvo LogoVolvo XC40 (This) 433 l
    433.0
Boot space (rear seats folded, bottom to roof)
1309 l
  • volvo LogoVolvo XC40 (This) 1309 l
    1,309.0
Seats
5
5
Doors
5
5

Engines/drivetrain

Cylinders
3 - 4
  • volvo LogoVolvo XC40 (This) 3 - 4
    3.0
Max. speed
160 - 180 km/h
  • volvo LogoVolvo XC40 (This) 160 - 180 km/h
Torque
245 - 670 Nm
  • volvo LogoVolvo XC40 (This) 245 - 670 Nm
    245.0
Power
95 - 300 kW
  • volvo LogoVolvo XC40 (This) 95 - 300 kW
    95.0
Cubic capacity
1477 - 1969 ccm
  • volvo LogoVolvo XC40 (This) 1477 - 1969 ccm
    1,477.0
Acceleration 0-100km/h
4 - 10 s
  • volvo LogoVolvo XC40 (This) 4 - 10 s

Consumption/ecology

Tank size
48 - 54 l
  • volvo LogoVolvo XC40 (This) 48 - 54 l
Combined consumption (WLTP)
2 - 23 l/100km
  • volvo LogoVolvo XC40 (This) 2 - 23 l/100km
Suburban consumption (WLTP)
6 - 7 l/100km
  • volvo LogoVolvo XC40 (This) 6 - 7 l/100km
    6.0
Consumption on highways (WLTP)
6 - 7 l/100km
  • volvo LogoVolvo XC40 (This) 6 - 7 l/100km
CO2 emissions (WLTP)
47 - 175 g/km
  • volvo LogoVolvo XC40 (This) 47 - 175 g/km
Empty weight (EU)
1580 - 2188 kg
  • volvo LogoVolvo XC40 (This) 1580 - 2188 kg
    1,580.0

Towing

Max. towbar load
100 - 110 kg
  • volvo LogoVolvo XC40 (This) 100 - 110 kg
Max. roof load
75 kg
  • volvo LogoVolvo XC40 (This) 75 kg
    75.0
Braked trailer
1500 - 2100 kg
  • volvo LogoVolvo XC40 (This) 1500 - 2100 kg
Trailer (no brakes)
750 kg
  • volvo LogoVolvo XC40 (This) 750 kg
    750.0

Offroad

Ramp angle
21 °
  • volvo LogoVolvo XC40 (This) 21 °
    21.0
Departure angle
30 °
  • volvo LogoVolvo XC40 (This) 30 °
    30.0
Approach angle
21 °
  • volvo LogoVolvo XC40 (This) 21 °
    21.0
Fording
450 mm
  • volvo LogoVolvo XC40 (This) 450 mm
    450.0

Engines (XC40)

Filter by fuel:
Gasoline
MAN FWD
T2 Essential
Engine & Power
Power
95 kW / 129 HP
Capacity
1.5L (1,477 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
10 s
Max. speed
180 km/h
Torque & RPM
Torque
245 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
158 g/km
Maximum torque at RPM
1600 RPM
Consumption on short trips (WLTP)
8 l/100km
Technical Details
Maximum output at RPM
5000 RPM
Fuel injection
Direct Injection
Gasoline
AUT FWD
T2 Essential Geartronic
Engine & Power
Power
95 kW / 129 HP
Capacity
1.5L (1,477 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
10 s
Max. speed
180 km/h
Torque & RPM
Torque
245 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
164 g/km
Maximum torque at RPM
1600 RPM
Consumption on short trips (WLTP)
10 l/100km
Technical Details
Maximum output at RPM
5000 RPM
Fuel injection
Direct Injection
Gasoline
AUT FWD
B3 Core DKG
Engine & Power
Power
120 kW / 163 HP
Capacity
2.0L (1,969 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
180 km/h
Torque & RPM
Torque
265 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
150 g/km
Maximum torque at RPM
1500 RPM
Consumption on short trips (WLTP)
9 l/100km
Technical Details
Maximum output at RPM
4750 RPM
Fuel injection
Direct Injection
Gasoline
AUT FWD
B4 Core DKG
Engine & Power
Power
145 kW / 197 HP
Capacity
2.0L (1,969 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
7 s
Max. speed
180 km/h
Torque & RPM
Torque
300 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
150 g/km
Maximum torque at RPM
1500 RPM
Consumption on short trips (WLTP)
9 l/100km
Technical Details
Maximum output at RPM
4750 RPM
Fuel injection
Direct Injection
Super / Strom
AUT FWD
Recharge Plug-in Hybrid T4 Essential DKG
Engine & Power
Power
155 kW / 211 HP
Capacity
1.5L (1,477 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
8 s
Max. speed
180 km/h
Torque & RPM
Torque
405 Nm
Consumption
Combined consumption (WLTP)
2 l/100km
Emissions
CO2 emissions (WLTP)
47 g/km
Maximum torque at RPM
1600 RPM
Consumption on short trips (WLTP)
8 l/100km
Technical Details
Maximum output at RPM
5000 RPM
Fuel injection
Direct Injection
Electric
AUT FWD
Recharge Pure Electric Single Core
Engine & Power
Power
170 kW / 231 HP
Battery
69 kWh
Range
423 km
Performance
Acceleration 0-100km/h
7 s
Max. speed
160 km/h
Torque & RPM
Torque
330 Nm
Consumption
Combined consumption (WLTP)
18 kWh/100km
Technical Details
Emission standard
Electric Vehicle
Gears
1
Electric
AUT Hinterrad
Recharge Pure Electric Single Motor Essential
Engine & Power
Power
175 kW / 238 HP
Battery
69 kWh
Range
478 km
Performance
Acceleration 0-100km/h
7 s
Max. speed
180 km/h
Torque & RPM
Torque
420 Nm
Consumption
Combined consumption (WLTP)
16 kWh/100km
Technical Details
Emission standard
Electric Vehicle
Gears
1
Gasoline
AUT AWD
B5 Ultimate Dark AWD Geartronic
Engine & Power
Power
184 kW / 250 HP
Capacity
2.0L (1,969 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
6 s
Max. speed
180 km/h
Torque & RPM
Torque
350 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
174 g/km
Maximum torque at RPM
1800 RPM
Consumption on short trips (WLTP)
11 l/100km
Technical Details
Maximum output at RPM
5400 RPM
Fuel injection
Direct Injection
Electric
AUT Hinterrad
Recharge Pure Electric Single Motor Extended Range Ultimate
Engine & Power
Power
185 kW / 252 HP
Battery
82 kWh
Range
575 km
Performance
Acceleration 0-100km/h
7 s
Max. speed
180 km/h
Torque & RPM
Torque
420 Nm
Consumption
Combined consumption (WLTP)
16 kWh/100km
Technical Details
Emission standard
Electric Vehicle
Gears
1
Super / Strom
AUT FWD
Recharge Plug-in Hybrid T5 Essential DKG
Engine & Power
Power
192 kW / 261 HP
Capacity
1.5L (1,477 ccm)
Cylinders
3
Performance
Acceleration 0-100km/h
7 s
Max. speed
180 km/h
Torque & RPM
Torque
425 Nm
Consumption
Combined consumption (WLTP)
2 l/100km
Emissions
CO2 emissions (WLTP)
47 g/km
Maximum torque at RPM
1500 RPM
Consumption on short trips (WLTP)
8 l/100km
Technical Details
Maximum output at RPM
5800 RPM
Fuel injection
Direct Injection
Electric
AUT AWD
Recharge Pure Electric Twin Core
Engine & Power
Power
300 kW / 408 HP
Battery
78 kWh
Range
418 km
Performance
Acceleration 0-100km/h
4 s
Max. speed
180 km/h
Torque & RPM
Torque
660 Nm
Consumption
Combined consumption (WLTP)
23 kWh/100km
Technical Details
Emission standard
Electric Vehicle
Gears
1
Electric
AUT AWD
Recharge Pure Electric Twin Motor Plus
Engine & Power
Power
300 kW / 408 HP
Battery
82 kWh
Range
541 km
Performance
Acceleration 0-100km/h
4 s
Max. speed
180 km/h
Torque & RPM
Torque
670 Nm
Consumption
Combined consumption (WLTP)
17 kWh/100km
Technical Details
Emission standard
Electric Vehicle
Gears
1
Compare all engines

Volvo XC40 generations

XC40 1.Generation
2018 - 2021
Length4425 mm
Height1652 mm
Wheelbase2702 mm
Length4425 mm
XC40 XC40 1. Generation (1. Facelift)
2022 - Now
Length4425 mm
Height1652 mm
Wheelbase2702 mm
Length4425 mm
Compare all generations

1927
1927
Volvo founded
2018
2018
1.Generation was introduced.
2021
2021
1.Generation was introduced.
2022
2022
XC40 1. Generation (1. Facelift) was introduced.
The image shows a side profile view of a modern SUV positioned on a smooth, neutral-colored surface, possibly in a studio or rendered environment. Specifically, the image captures the vehicle from a three-quarter front angle, showcasing the Volvo XC40 2022 (1st generation-facelift) driver's side. Notable features visible include a distinctive grille, possibly with LED headlights and daytime running lights, sleek aerodynamic design with flush door handles, multi-spoke alloy wheels, body-colored side mirrors likely with integrated turn signal indicators, rugged contrasting trim, and a gently sloping roofline with a roof spoiler. The visible rear hints at a complementary tail light design possibly incorporating LED technology.
Full side profile of a parked Volvo XC40 2022 (1st generation, facelift) with detailed view of side mirrors, door handles, and alloy wheels in an industrial setting with soft and even lighting.
The image shows a Volvo XC40 2022 (1st generation facelift) in an industrial or architectural setting with large cylindrical structures. Captured from a three-quarter front angle, the picture highlights the car's sleek and modern design, including sharp LED headlights and a distinctive grille. The spacious environment and soft lighting emphasize its premium features such as advanced lighting technology, high-quality paintwork, and sophisticated wheels, all suggestive of a performance or luxury variant.
