Mercedes-Benz B-class
Specs, engines, generations

Thumbnail 1
Table of contents:

Model specs

Model info

Model name
Mercedes-Benz B-class
Generation
W247
Production years
2022 - Present
Doors
5
5

Dimensions

Length
4419 mm
4,386.0
Avg
5,125.0
Higher is better
Wheelbase
2729 mm
2,670.0
Avg
3,000.0
Higher is better
Width
1796 mm
1,796.0
Avg
1,890.0
Higher is better
Height
1562 mm
1,562.0
Avg
1,940.0
Higher is better
Ground clearance
104 mm
104.0
Avg
171.0
Higher is better
Turning circle
11 m
11.0
Avg
13.0
Lower is better

Boot/interior

Boot space
445 l
445.0
Avg
752.0
Higher is better
Boot space (rear seats folded, bottom to roof)
1530 l
752.0
Avg
1,540.0
Higher is better
Seats
5
5
Doors
5
5

Engines/drivetrain

Cylinders
4
3.0
Avg
4.0
Higher is better
Max. speed
200 - 250 km/h
190.0
Avg
214.0
Higher is better
Torque
200 - 450 Nm
200.0
Avg
230.0
Higher is better
Power
85 - 175 kW
85.0
Avg
184.0
Higher is better
Cubic capacity
1332 - 1991 ccm
1,332.0
Avg
2,487.0
Higher is better
Acceleration 0-100km/h
6 - 10 s
6.0
Avg
9.0
Higher is better

Consumption/ecology

Tank size
35 - 51 l
35.0
Avg
60.0
Higher is better
Combined consumption (WLTP)
5 - 7 l/100km
5.0
Avg
7.0
Higher is better
Suburban consumption (WLTP)
5 - 6 l/100km
  • lexus LogoLexus LM 6 l/100km
    6.0
  • mercedes-benz LogoMercedes-Benz B-Klasse (This) 5 - 6 l/100km
5.0
Avg
6.0
Higher is better
Consumption on highways (WLTP)
4 - 6 l/100km
  • lexus LogoLexus LM 8 l/100km
    8.0
  • mercedes-benz LogoMercedes-Benz B-Klasse (This) 4 - 6 l/100km
4.0
Avg
8.0
Higher is better
CO2 emissions (WLTP)
18 - 162 g/km
18.0
Avg
163.0
Higher is better
Empty weight (EU)
1405 - 1750 kg
1,405.0
Avg
2,345.0
Higher is better

Towing

Max. towbar load
80 kg
75.0
Avg
80.0
Higher is better
Max. roof load
75 kg
75.0
Avg
75.0
Higher is better
Braked trailer
1400 - 1800 kg
1,300.0
Avg
1,400.0
Higher is better
Trailer (no brakes)
745 - 750 kg
745.0
Avg
750.0
Higher is better

Engines (B-class)

Filter by fuel:
Diesel
AUT FWD
B 180 d 8G-DCT
Engine & Power
Power
85 kW / 116 HP
Capacity
2.0L (1,950 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
200 km/h
Torque & RPM
Torque
280 Nm
Consumption
Combined consumption (WLTP)
5 l/100km
Emissions
CO2 emissions (WLTP)
136 g/km
Maximum torque at RPM
1750 RPM
Technical Details
Maximum output at RPM
3400 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
B 200 d 8G-DCT
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,950 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
219 km/h
Torque & RPM
Torque
320 Nm
Consumption
Combined consumption (WLTP)
5 l/100km
Emissions
CO2 emissions (WLTP)
133 g/km
Maximum torque at RPM
1400 RPM
Technical Details
Maximum output at RPM
3400 RPM
Fuel injection
Common Rail
Gasoline
AUT FWD
B 180 7G-DCT
Engine & Power
Power
110 kW / 150 HP
Capacity
1.3L (1,332 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
212 km/h
Torque & RPM
Torque
200 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
138 g/km
Maximum torque at RPM
1460 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Gasoline
AUT FWD
B 200 7G-DCT
Engine & Power
Power
130 kW / 177 HP
Capacity
1.3L (1,332 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
223 km/h
Torque & RPM
Torque
250 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
138 g/km
Maximum torque at RPM
1620 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Diesel
AUT FWD
B 220 d 8G-DCT
Engine & Power
Power
140 kW / 190 HP
Capacity
2.0L (1,950 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
7 s
Max. speed
234 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
5 l/100km
Emissions
CO2 emissions (WLTP)
135 g/km
Maximum torque at RPM
1600 RPM
Technical Details
Maximum output at RPM
3800 RPM
Fuel injection
Common Rail
Gasoline
AUT AWD
B 200 4MATIC 8G-DCT
Engine & Power
Power
150 kW / 204 HP
Capacity
1.3L (1,332 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
7 s
Max. speed
234 km/h
Torque & RPM
Torque
250 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
159 g/km
Maximum torque at RPM
1620 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Super / Strom
AUT FWD
B 250 e 8G-DCT
Engine & Power
Power
160 kW / 218 HP
Capacity
1.3L (1,332 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
7 s
Max. speed
223 km/h
Torque & RPM
Torque
450 Nm
Emissions
CO2 emissions (WLTP)
21 g/km
Maximum torque at RPM
1620 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Super / Strom
AUT FWD
B 250 e 8G-DCT
Engine & Power
Power
160 kW / 218 HP
Capacity
1.3L (1,332 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
7 s
Max. speed
223 km/h
Torque & RPM
Torque
450 Nm
Emissions
CO2 emissions (WLTP)
21 g/km
Maximum torque at RPM
1620 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Gasoline
AUT AWD
B 250 Progressive 4MATIC 7G-DCT
Engine & Power
Power
175 kW / 238 HP
Capacity
2.0L (1,991 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
6 s
Max. speed
250 km/h
Torque & RPM
Torque
350 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
162 g/km
Maximum torque at RPM
1800 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Compare all engines

Mercedes-Benz B-class generations

Body type
B-Klasse B-Klasse 245
2005 - 2008
Length4270 mm
Height1604 mm
Wheelbase2778 mm
Length4270 mm
Body type
B-Klasse B-Klasse 245 (1. Facelift)
2008 - 2011
Length4273 mm
Height1604 mm
Wheelbase2778 mm
Length4273 mm (+3 mm)
Body type
B-Klasse B-Klasse 246
2011 - 2014
Length4359 mm
Height1557 mm
Wheelbase2699 mm
Length4359 mm (+86 mm)
Body type
B-Klasse B-Klasse 246/242 (1. Facelift)
2014 - 2018
Length4393 mm
Height1557 mm
Wheelbase2699 mm
Length4393 mm (+34 mm)
Body type
B-Klasse B-Klasse 247
2019 - 2022
Length4419 mm
Height1562 mm
Wheelbase2729 mm
Length4419 mm (+26 mm)
B-Klasse B-Klasse 247 (1. Facelift)
2022 - Now
Length4419 mm
Height1562 mm
Wheelbase2729 mm
Length4419 mm
Compare all generations

1926
1926
Mercedes-Benz founded
2005
2005
B-Klasse 245 was introduced.
2008
2008
B-Klasse 245 (1. Facelift) was introduced and replaced B-Klasse 245.
2011
2011
B-Klasse 246 was introduced and replaced B-Klasse 245 (1. Facelift).
2014
2014
B-Klasse 246/242 (1. Facelift) was introduced and replaced B-Klasse 246.
2018
2018
B-Klasse 246/242 (1. Facelift) was introduced and replaced B-Klasse 246.
2019
2019
B-Klasse 247 was introduced.
2022
2022
B-Klasse 247 (1. Facelift) was introduced and replaced B-Klasse 247.
