Ford Transit Custom (2018 - 2023)

Thumbnail 1
Table of contents:

Variants

Van
Transit Custom -VAN
BodyVan
Length4973 mm
Height2000 mm
Doors4
Bus
Transit Custom Kombi
BodyBus
Length4972 mm
Height1972 mm
Doors4
Motorhome
Transit Custom Kombi Nugget
BodyMotorhome
Length4972 mm
Height2060 mm
Doors4

Model specs

Model info

Model name
Ford Transit Custom
Generation
F*C
Production years
2018 - 2023
Doors
4
4

Dimensions

Length
4972 mm
4,403.0
Avg
5,995.0
Higher is better
Wheelbase
2933 mm
2,785.0
Avg
3,182.0
Higher is better
Width
1986 mm
1,780.0
Avg
2,070.0
Higher is better
Height
1972 mm
1,795.0
Avg
2,590.0
Higher is better
Turning circle
11 m
10.0
Avg
12.0
Lower is better

Boot/interior

Seats
9
9
Doors
4
4

Engines/drivetrain

Cylinders
3 - 4
3.0
Avg
4.0
Higher is better
Max. speed
165 km/h
100.0
Avg
174.0
Higher is better
Torque
310 - 415 Nm
205.0
Avg
400.0
Higher is better
Power
77 - 136 kW
77.0
Avg
150.0
Higher is better
Cubic capacity
998 - 1995 ccm
998.0
Avg
2,393.0
Higher is better

Consumption/ecology

Tank size
70 l
55.0
Avg
81.0
Higher is better
Combined consumption (NEDC)
5 - 18 l/100km
  • fiat LogoFiat Ducato 6 l/100km
    6.0
  • ford LogoFord Transit Custom (This) 5 - 18 l/100km
5.0
Avg
6.0
Higher is better
City consumption (NEDC)
5 - 7 l/100km
  • fiat LogoFiat Ducato 8 l/100km
    8.0
  • ford LogoFord Transit Custom (This) 5 - 7 l/100km
5.0
Avg
8.0
Higher is better
Combined consumption (WLTP)
7 - 19 l/100km
6.0
Avg
27.0
Higher is better
Suburban consumption (WLTP)
6 - 8 l/100km
6.0
Avg
7.0
Higher is better
Consumption on highways (WLTP)
8 - 9 l/100km
7.0
Avg
10.0
Higher is better
CO2 emissions (WLTP)
74 - 226 g/km
74.0
Avg
250.0
Higher is better
Empty weight (EU)
1990 - 2804 kg
1,284.0
Avg
2,700.0
Higher is better

Towing

Max. roof load
150 kg
50.0
Avg
150.0
Higher is better
Braked trailer
1000 - 2800 kg
900.0
Avg
2,800.0
Higher is better

Engines (Transit Custom)

Filter by fuel:
Diesel
MAN FWD
Kombi 320 L1 2.0 TDCi
Engine & Power
Power
77 kW / 105 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
360 Nm
Consumption
Combined consumption (NEDC)
6 l/100km
Maximum torque at RPM
1375 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Electric
AUT FWD
-VAN 340 L1H1 1.0 EcoBoost PHEV -automatic
Engine & Power
Power
92 kW / 125 HP
Battery
13 kWh
Torque & RPM
Torque
355 Nm
Consumption
Combined consumption (NEDC)
18 kWh/100km
Technical Details
Fuel injection
Direct Injection
Engine type
Turbocharged
Diesel
MAN FWD
Kombi 320 L1 2.0 TDCi
Engine & Power
Power
96 kW / 131 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
385 Nm
Consumption
Combined consumption (NEDC)
6 l/100km
Maximum torque at RPM
1500 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
Kombi 320 L1 2.0 TDCi Trend -automatic
Engine & Power
Power
96 kW / 131 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
385 Nm
Consumption
Combined consumption (NEDC)
7 l/100km
Maximum torque at RPM
1500 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
Kombi 320 L1 Nugget Aufstelldach 2.0 EcoBlue Trend
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
360 Nm
Consumption
Combined consumption (WLTP)
7 l/100km
Emissions
CO2 emissions (WLTP)
205 g/km
Maximum torque at RPM
1500 RPM
Consumption on short trips (WLTP)
9 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
Kombi 340 L2 Nugget Plus Hochdach 2.0 EcoBlue Trend -automatic
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
360 Nm
Consumption
Combined consumption (WLTP)
8 l/100km
Emissions
CO2 emissions (WLTP)
226 g/km
Maximum torque at RPM
1500 RPM
Consumption on short trips (WLTP)
10 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
Kombi 340 L1 2.0 TDCi Trend
Engine & Power
Power
125 kW / 170 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
405 Nm
Consumption
Combined consumption (NEDC)
6 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
Kombi 320 L1 2.0 TDCi Trend -automatic
Engine & Power
Power
125 kW / 170 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
405 Nm
Consumption
Combined consumption (NEDC)
7 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
Kombi 340 L2 2.0 EcoBlue
Engine & Power
Power
136 kW / 185 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
415 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
Kombi 320 L1 2.0 EcoBlue Trend -automatic
Engine & Power
Power
136 kW / 185 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Torque & RPM
Torque
415 Nm
Consumption
Combined consumption (NEDC)
6 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
7 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Compare all engines

Ford Transit Custom generations

Body type
Transit Custom 1.Generation
2012 - 2018
Length4972 mm
Height1972 mm
Wheelbase2933 mm
Length4972 mm
Transit Custom Transit Custom 1. Generation (1. Facelift)
2018 - 2023
Length4972 mm
Height2060 mm
Wheelbase2933 mm
Length4972 mm
Transit Custom Transit Custom 2. Generation
2023 - Now
Length5050 mm
Height1958 mm
Wheelbase3100 mm
Length5050 mm (+78 mm)
Compare all generations

1903
1903
Ford founded
2012
2012
1.Generation was introduced.
2018
2018
Transit Custom 1. Generation (1. Facelift) was introduced and replaced 1.Generation.
2023
2023
Transit Custom 2. Generation was introduced and replaced Transit Custom 1. Generation (1. Facelift).
