2019
Compare
Engines

Ford S-MAX (2019 - 2023)

Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Table of contents:

Model specs

Model info

Model name
Ford S-MAX
Generation
WA6
Production years
2019 - 2023
Doors
5
5

Dimensions

Length
4796 mm
4,527.0
Avg
5,080.0
Higher is better
Wheelbase
2850 mm
2,786.0
Avg
3,124.0
Higher is better
Width
1916 mm
1,784.0
Avg
2,050.0
Higher is better
Height
1655 mm
1,655.0
Avg
2,254.0
Higher is better
Ground clearance
148 mm
148.0
Avg
207.0
Higher is better
Turning circle
11 m
11.0
Avg
12.0
Lower is better

Boot/interior

Boot space (rear seats folded, bottom to roof)
2020 l
1,807.0
Avg
4,700.0
Higher is better
Seats
5
5
Max. seats
7
7
Doors
5
5

Engines/drivetrain

Cylinders
4
3.0
Avg
4.0
Higher is better
Max. speed
182 - 218 km/h
145.0
Avg
203.0
Higher is better
Torque
242 - 500 Nm
175.0
Avg
310.0
Higher is better
Power
110 - 177 kW
81.0
Avg
150.0
Higher is better
Cubic capacity
1499 - 2488 ccm
999.0
Avg
1,997.0
Higher is better
Acceleration 0-100km/h
8 - 10 s
8.0
Avg
16.0
Higher is better

Consumption/ecology

Tank size
61 - 65 l
50.0
Avg
81.0
Higher is better
Combined consumption (WLTP)
5 - 8 l/100km
5.0
Avg
22.0
Higher is better
Suburban consumption (WLTP)
5 l/100km
5.0
Avg
15.0
Higher is better
Consumption on highways (WLTP)
6 l/100km
6.0
Avg
26.0
Higher is better
CO2 emissions (WLTP)
145 - 195 g/km
129.0
Avg
191.0
Higher is better
Empty weight (EU)
1784 - 1984 kg
1,280.0
Avg
2,487.0
Higher is better

Towing

Max. towbar load
90 kg
75.0
Avg
100.0
Higher is better
Max. roof load
75 kg
75.0
Avg
200.0
Higher is better
Braked trailer
1560 - 2000 kg
400.0
Avg
2,500.0
Higher is better
Trailer (no brakes)
750 kg
400.0
Avg
750.0
Higher is better

Engines (S-MAX)

Filter by fuel:
Diesel
MAN FWD
2.0 EcoBlue Trend
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
198 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
157 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 EcoBlue Trend -automatic
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
196 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
170 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Gasoline
MAN FWD
1.5 EcoBoost Start/Stopp Trend
Engine & Power
Power
121 kW / 165 HP
Capacity
1.5L (1,499 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
203 km/h
Torque & RPM
Torque
242 Nm
Consumption
Combined consumption (WLTP)
8 l/100km
Emissions
CO2 emissions (WLTP)
191 g/km
Maximum torque at RPM
1650 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Diesel
AUT FWD
2.0 EcoBlue Trend -automatic
Engine & Power
Power
140 kW / 190 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
208 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
169 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Super / Strom
AUT FWD
2.5 Hybrid Trend
Engine & Power
Power
140 kW / 190 HP
Capacity
2.5L (2,488 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
182 km/h
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
146 g/km
Torque & RPM
Maximum torque at RPM
4500 RPM
Consumption on short trips (WLTP)
8 l/100km
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Injection
Diesel
AUT FWD
2.0 EcoBlue Bi-Turbo ST-Line -automatic
Engine & Power
Power
177 kW / 241 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
218 km/h
Torque & RPM
Torque
500 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
175 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
4000 RPM
Fuel injection
Common Rail
Compare all engines

Ford S-MAX generations

Body type
S-MAX I
2006 - 2010
Length4768 mm
Height1658 mm
Wheelbase2850 mm
Length4768 mm
Body type
S-MAX I (1. Facelift)
2010 - 2015
Length4772 mm
Height1658 mm
Wheelbase2850 mm
Length4772 mm (+4 mm)
S-MAX II
2015 - 2019
Length4796 mm
Height1655 mm
Wheelbase2850 mm
Length4796 mm (+24 mm)
S-MAX S-MAX II (1. Facelift)
2019 - 2023
Length4796 mm
Height1655 mm
Wheelbase2850 mm
Length4796 mm
Compare all generations

1903
1903
Ford founded
2006
2006
I was introduced.
2010
2010
I (1. Facelift) was introduced and replaced I.
2015
2015
II was introduced and replaced I (1. Facelift).
2019
2019
S-MAX II (1. Facelift) was introduced and replaced II.
2023
2023
The production of Ford S-MAX was discontinued.
