Ford S-MAX (2015 - 2019)

Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Thumbnail 1
Table of contents:

Model specs

Model info

Model name
Ford S-MAX
Generation
WA6
Production years
2015 - 2019
Doors
5
5

Dimensions

Length
4796 mm
4,527.0
Avg
5,080.0
Higher is better
Wheelbase
2850 mm
2,786.0
Avg
3,124.0
Higher is better
Width
1916 mm
1,784.0
Avg
2,050.0
Higher is better
Height
1655 mm
1,655.0
Avg
2,254.0
Higher is better
Ground clearance
148 mm
148.0
Avg
207.0
Higher is better
Turning circle
11 m
11.0
Avg
12.0
Lower is better
Annotated Image

Boot/interior

Boot space (rear seats folded, bottom to roof)
2020 l
1,807.0
Avg
4,700.0
Higher is better
Seats
5
5
Max. seats
7
7
Doors
5
5

Engines/drivetrain

Cylinders
4
3.0
Avg
4.0
Higher is better
Max. speed
180 - 226 km/h
145.0
Avg
200.0
Higher is better
Torque
240 - 500 Nm
175.0
Avg
310.0
Higher is better
Power
88 - 177 kW
81.0
Avg
150.0
Higher is better
Cubic capacity
1498 - 1999 ccm
999.0
Avg
1,997.0
Higher is better
Acceleration 0-100km/h
8 - 13 s
8.0
Avg
16.0
Higher is better

Consumption/ecology

Tank size
61 - 70 l
50.0
Avg
81.0
Higher is better
Combined consumption (NEDC)
5 - 7 l/100km
5.0
Avg
6.0
Higher is better
City consumption (NEDC)
5 - 10 l/100km
5.0
Avg
8.0
Higher is better
Combined consumption (WLTP)
6 - 8 l/100km
5.0
Avg
22.0
Higher is better
CO2 emissions (WLTP)
157 - 195 g/km
129.0
Avg
185.0
Higher is better
Empty weight (EU)
1645 - 1984 kg
1,280.0
Avg
2,487.0
Higher is better

Towing

Max. towbar load
90 kg
75.0
Avg
100.0
Higher is better
Max. roof load
75 kg
75.0
Avg
200.0
Higher is better
Braked trailer
1500 - 2000 kg
400.0
Avg
2,500.0
Higher is better
Trailer (no brakes)
750 kg
400.0
Avg
750.0
Higher is better

Engines (S-MAX)

Filter by fuel:
Diesel
MAN FWD
2.0 TDCi Start/Stopp Trend
Engine & Power
Power
88 kW / 120 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
13 s
Max. speed
183 km/h
Torque & RPM
Torque
310 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
2.0 EcoBlue Trend
Engine & Power
Power
88 kW / 120 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
12 s
Max. speed
180 km/h
Torque & RPM
Torque
340 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
157 g/km
Maximum torque at RPM
1750 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
2.0 TDCi Start/Stopp Trend
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
198 km/h
Torque & RPM
Torque
350 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3750 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
2.0 EcoBlue Trend
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
198 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
157 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 TDCi Start/Stopp Trend Powershift
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
196 km/h
Torque & RPM
Torque
350 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3750 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 EcoBlue Trend -automatic
Engine & Power
Power
110 kW / 150 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
196 km/h
Torque & RPM
Torque
370 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
170 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Gasoline
MAN FWD
1.5 EcoBoost Start/Stopp Trend
Engine & Power
Power
118 kW / 160 HP
Capacity
1.5L (1,498 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
200 km/h
Torque & RPM
Torque
240 Nm
Consumption
Combined consumption (NEDC)
6 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
8 l/100km
Technical Details
Maximum output at RPM
5700 RPM
Fuel injection
Direct Injection
Gasoline
MAN FWD
1.5 EcoBoost Start/Stopp Trend
Engine & Power
Power
121 kW / 165 HP
Capacity
1.5L (1,499 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
10 s
Max. speed
203 km/h
Torque & RPM
Torque
242 Nm
Consumption
Combined consumption (WLTP)
8 l/100km
Emissions
CO2 emissions (WLTP)
191 g/km
Maximum torque at RPM
1600 RPM
Technical Details
Maximum output at RPM
5500 RPM
Fuel injection
Direct Injection
Diesel
MAN FWD
2.0 TDCi Start/Stopp Trend
Engine & Power
Power
132 kW / 180 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
211 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3750 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 TDCi Start/Stopp Trend Powershift
Engine & Power
Power
132 kW / 180 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
208 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
2000 RPM
City consumption (NEDC)
5 l/100km
Technical Details
Maximum output at RPM
3750 RPM
Fuel injection
Common Rail
Diesel
MAN FWD
2.0 EcoBlue Trend
Engine & Power
Power
140 kW / 190 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
211 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
157 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 EcoBlue Trend -automatic
Engine & Power
Power
140 kW / 190 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
9 s
Max. speed
208 km/h
Torque & RPM
Torque
400 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
169 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 TDCi Bi-Turbo Start/Stopp Titanium Powershift
Engine & Power
Power
154 kW / 209 HP
Capacity
2.0L (1,997 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
218 km/h
Torque & RPM
Torque
450 Nm
Consumption
Combined consumption (NEDC)
5 l/100km
Maximum torque at RPM
1750 RPM
City consumption (NEDC)
6 l/100km
Technical Details
Maximum output at RPM
3500 RPM
Fuel injection
Common Rail
Diesel
AUT FWD
2.0 EcoBlue Bi-Turbo Titanium -automatic
Engine & Power
Power
177 kW / 241 HP
Capacity
2.0L (1,995 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
218 km/h
Torque & RPM
Torque
500 Nm
Consumption
Combined consumption (WLTP)
6 l/100km
Emissions
CO2 emissions (WLTP)
172 g/km
Maximum torque at RPM
2000 RPM
Technical Details
Maximum output at RPM
4000 RPM
Fuel injection
Common Rail
Gasoline
AUT FWD
2.0 EcoBoost Start/Stopp Trend Automatik
Engine & Power
Power
177 kW / 241 HP
Capacity
2.0L (1,999 ccm)
Cylinders
4
Performance
Acceleration 0-100km/h
8 s
Max. speed
226 km/h
Torque & RPM
Torque
340 Nm
Consumption
Combined consumption (NEDC)
7 l/100km
Maximum torque at RPM
1900 RPM
City consumption (NEDC)
10 l/100km
Technical Details
Maximum output at RPM
6000 RPM
Fuel injection
Direct Injection
Compare all engines

Ford S-MAX generations

Body type
S-MAX I
2006 - 2010
Length4768 mm
Height1658 mm
Wheelbase2850 mm
Length4768 mm
Body type
S-MAX I (1. Facelift)
2010 - 2015
Length4772 mm
Height1658 mm
Wheelbase2850 mm
Length4772 mm (+4 mm)
S-MAX II
2015 - 2019
Length4796 mm
Height1655 mm
Wheelbase2850 mm
Length4796 mm (+24 mm)
S-MAX S-MAX II (1. Facelift)
2019 - 2023
Length4796 mm
Height1655 mm
Wheelbase2850 mm
Length4796 mm
Compare all generations

1903
1903
Ford founded
2006
2006
I was introduced.
2010
2010
I (1. Facelift) was introduced and replaced I.
2015
2015
II was introduced and replaced I (1. Facelift).
2019
2019
S-MAX II (1. Facelift) was introduced and replaced II.
2023
2023
The production of Ford S-MAX was discontinued.

Similar cars

VW Touran
VW Touran
vw Logo 2015 • 5T
Body type
Minivan
Length
4527 mm
Width
1829 mm
Height
1668 mm
Wheelbase
2786 mm
Boot capacity
834 l
Weight
1436 kg
Doors
5
Compare
Dacia Jogger
Dacia Jogger
dacia Logo 2022 • DJF
Body type
Minivan
Length
4547 mm
Width
1784 mm
Height
1674 mm
Wheelbase
2897 mm
Boot capacity
160 l
Weight
1280 kg
Doors
5
Compare
VW Nutzfahrzeuge Transporter
VW Nutzfahrzeuge Transporter
2021 • ST
Body type
Bus
Length
4973 mm
Width
1941 mm
Height
1907 mm
Wheelbase
3124 mm
Boot capacity
469 l
Weight
1941 kg
Doors
5
Compare
Fiat Ducato
Fiat Ducato
fiat Logo 2014 • ZAF 250
Body type
Bus
Length
4963 mm
Width
2050 mm
Height
2254 mm
Wheelbase
3000 mm
Weight
2010 kg
Doors
4
Compare
Renault Trafic
Renault Trafic
renault Logo 2021 • L/JL
Body type
Bus
Length
5080 mm
Width
1956 mm
Height
1973 mm
Wheelbase
3098 mm
Weight
2041 kg
Doors
4
Compare
Nissan Primastar
Nissan Primastar
nissan Logo 2021 • 4/J4
Body type
Bus
Length
5080 mm
Width
1956 mm
Height
1935 mm
Wheelbase
3098 mm
Weight
1992 kg
Doors
4
Compare
Maxus Euniq 5
Maxus Euniq 5
2023 • SV5A
Body type
Minivan
Length
4825 mm
Width
1825 mm
Height
1800 mm
Wheelbase
2800 mm
Weight
1810 kg
Doors
5
Compare
VW Nutzfahrzeuge ID. Buzz
VW Nutzfahrzeuge ID. Buzz
2022 • EB
Body type
Bus
Length
4712 mm
Width
1985 mm
Height
1927 mm
Wheelbase
2989 mm
Boot capacity
1121 l
Weight
2487 kg
Doors
5
Compare
Ford Kuga
Ford Kuga
ford Logo 2019 • DFK
Body type
SUV
Length
4614 mm
Width
1883 mm
Height
1661 mm
Wheelbase
2710 mm
Boot capacity
435 l
Weight
1564 kg
Doors
5
Compare
Toyota RAV4
Toyota RAV4
toyota Logo 2019 • XA5
Body type
SUV
Length
4600 mm
Width
1855 mm
Height
1685 mm
Wheelbase
2690 mm
Boot capacity
580 l
Weight
1615 kg
Doors
5
Compare
Mazda CX-30
Mazda CX-30
mazda Logo 2019 • DM
Body type
SUV
Length
4395 mm
Width
1795 mm
Height
1540 mm
Wheelbase
2655 mm
Boot capacity
430 l
Weight
1395 kg
Doors
5
Compare
Compare against all competitors

Compare with ...

Find the Perfect Match
Compare your car with other models
Comparing with:
Ford S-MAX (2015)

Crashtest

1. Overall rating 82%
2. Child passenger safety 87%
3. Adult passenger safety 87%
4. Pedestrian protection 79%
5. Safety assistance systems 71%

Reviews

TOPlist echo ''; // Add smooth scrolling JS for the generations and variants containers echo '';
